   HSK Type  GX (mm)  L (mm)  ØD5 (mm)  Torque for holder Assembly Nm/In Lbs.  HSK-A 100 COOLANT TUBE  M24x1.5  44.2  16  30Nm/..

 HSK Type  D1  L  D  HSK-A 100 COOLANT TUBE SPANNER  16.2  136  22..

   HSK Type  GX (mm)  L (mm)  ØD5 (mm)  Torque for holder Assembly Nm/In Lbs.  HSK-A 125 COOLANT TUBE  M30X1.5  48.0  18  35Nm/..

   HSK Type  GX (mm)  L (mm)  ØD5 (mm)  Torque for holder Assembly Nm/In Lbs.  HSK-A 32 COOLANT TUBE  M10x1  26.70  6  7Nm/..

   HSK Type  GX (mm)  L (mm)  ØD5 (mm)  Torque for holder Assembly Nm/In Lbs.  HSK-A 40 COOLANT TUBE  M12x1  29.5  8  11Nm/..

 HSK Type  D1  L  D  HSK-A 40 COOLANT TUBE SPANNER      ..

   HSK Type  GX (mm)  L (mm)  ØD5 (mm)  Torque for holder Assembly Nm/In Lbs.  HSK-A 50 COOLANT TUBE  M16X1  33.20  10  15Nm/..

 HSK Type  D1  L  D  HSK-A 50 COOLANT TUBE SPANNER  10.2  115  14.5..

   HSK Type  GX (mm)  L (mm)  ØD5 (mm)  Torque for holder Assembly Nm/In Lbs.  HSK-A 63 COOLANT TUBE  M18X1  36.60  12  20Nm/..

 HSK Type  D1  L  D  HSK-A 63 COOLANT TUBE SPANNER  12.2  136  16.5..

   HSK Type  GX (mm)  L (mm)  ØD5 (mm)  Torque for holder Assembly Nm/In Lbs.  HSK-A 80 COOLANT TUBE  M20x1.5  40.10  14  25Nm/..

T4 is referred to as C4 and both are compatible. *Capto is a trademark of Coromant Capto® and Sandvik Coromant and is used only for identification purposes. Compatible with C4 spindles, but not licensed.  Item Name  d  D  L1  L2  M ..
