| Item Name | ISO | Suitable Collet | Collet Capacity | D1 | D2 | G | L | Nut | Spanner |
|---|---|---|---|---|---|---|---|---|---|
| BBT40 ER16 070 ER Collet Chuck (Balanced to G2.5 25000 rpm) (BT MAS 403) (DIN 6499) | 40 | ER16 | 0.5 - 10 | 32 | - | M10X1P | 70 | UM/ER16 | E16 |
| BBT40 ER16 100 ER Collet Chuck (Balanced to G2.5 25000 rpm) (BT MAS 403) (DIN 6499) | 40 | ER16 | 0.5 - 10 | 22 | 22 | M10X1P | 100 | UM/ER16 | E16 |
| BBT40 ER16 130 ER Collet Chuck (Balanced to G2.5 25000 rpm) (BT MAS 403) (DIN 6499) | 40 | ER16 | 0.5 - 10 | 32 | 28 | M10X1P | 130 | UM/ER16 | E16 |
| BBT40 ER16 160 ER Collet Chuck (Balanced to G2.5 25000 rpm) (BT MAS 403) (DIN 6499) | 40 | ER16 | 0.5 - 10 | 32 | 28 | M10X1P | 160 | UM/ER16 | E16 |
| BBT40 ER20 070 ER Collet Chuck (Balanced to G2.5 25000 rpm) (BT MAS 403) (DIN 6499) | 40 | ER20 | 1.0 - 13 | 35 | - | M10X1P | 70 | UM/ER20 | E20 |
| BBT40 ER20 100 ER Collet Chuck (Balanced to G2.5 25000 rpm) (BT MAS 403) (DIN 6499) | 40 | ER20 | 1.0 - 13 | 35 | 33 | M10X1P | 100 | UM/ER20 | E20 |
| BBT40 ER20 130 ER Collet Chuck (Balanced to G2.5 25000 rpm) (BT MAS 403) (DIN 6499) | 40 | ER20 | 1.0 - 13 | 28 | 28 | M10X1P | 130 | UM/ER20 | E20 |
| BBT40 ER20 160 ER Collet Chuck (Balanced to G2.5 25000 rpm) (BT MAS 403) (DIN 6499) | 40 | ER20 | 1.0 - 13 | 35 | 33 | M10X1P | 160 | UM/ER20 | E20 |
| BBT40 ER25 070 ER Collet Chuck (Balanced to G2.5 25000 rpm) (BT MAS 403) (DIN 6499) | 40 | ER25 | 1.0 - 16 | 42 | - | M18X1P | 70 | UM/ER25 | E25 |
| BBT40 ER25 100 ER Collet Chuck (Balanced to G2.5 25000 rpm) (BT MAS 403) (DIN 6499) | 40 | ER25 | 1.0 - 16 | 42 | 40 | M18X1P | 100 | UM/ER25 | E25 |
| BBT40 ER25 130 ER Collet Chuck (Balanced to G2.5 25000 rpm) (BT MAS 403) (DIN 6499) | 40 | ER25 | 1.0 - 13 | 35 | 33 | M10X1P | 130 | UM/ER25 | E25 |
| BBT40 ER25 160 ER Collet Chuck (Balanced to G2.5 25000 rpm) (BT MAS 403) (DIN 6499) | 40 | ER25 | 1.0 - 16 | 42 | 40 | M18X1P | 160 | UM/ER25 | E25 |
| BBT40 ER32 070 ER Collet Chuck (Balanced to G2.5 25000 rpm) (BT MAS 403) (DIN 6499) | 40 | ER32 | 2.0 - 20 | 50 | - | M22X1.5P | 70 | UM/ER32 | E32 |
| BBT40 ER32 100 ER Collet Chuck (Balanced to G2.5 25000 rpm) (BT MAS 403) (DIN 6499) | 40 | ER32 | 2.0 - 20 | 50 | 48 | M22X1.5P | 100 | UM/ER32 | E32 |
| BBT40 ER32 130 ER Collet Chuck (Balanced to G2.5 25000 rpm) (BT MAS 403) (DIN 6499) | 40 | ER32 | 2.0 - 20 | 50 | 48 | M22X1.5P | 130 | UM/ER32 | E32 |
| BBT40 ER32 160 ER Collet Chuck (Balanced to G2.5 25000 rpm) (BT MAS 403) (DIN 6499) | 40 | ER32 | 2.0 - 20 | 50 | 48 | M22X1.5P | 160 | UM/ER32 | E32 |
| BBT40 ER40 070 ER Collet Chuck (Balanced to G2.5 25000 rpm) (BT MAS 403) (DIN 6499) | 40 | ER40 | 3.0 - 26 | 63 | - | M30X1.5P | 70 | UM/ER40 | E40 |
| BBT40 ER40 100 ER Collet Chuck (Balanced to G2.5 25000 rpm) (BT MAS 403) (DIN 6499) | 40 | ER40 | 3.0 - 26 | 63 | - | M30X1.5P | 100 | UM/ER40 | E40 |
| BBT40 ER40 130 ER Collet Chuck (Balanced to G2.5 25000 rpm) (BT MAS 403) (DIN 6499) | 40 | ER40 | 3.0 - 26 | 63 | - | M30X1.5P | 130 | UM/ER40 | E40 |
| BBT40 ER40 160 ER Collet Chuck (Balanced to G2.5 25000 rpm) (BT MAS 403) (DIN 6499) | 40 | R40 | 3.0 - 26 | 63 | - | M30X1.5P | 160 | UM/ER40 | E40 |
| BBT40 ER50 100 ER Collet Chuck (Balanced to G2.5 25000 rpm) (BT MAS 403) (DIN 6499) | 40 | ER50 | 10.0 - 34 | 78 | - | M16X2 | 100 | UM/ER50 | E50 |
| BBT40 ER11M 070 ER Collet Chuck (Balanced to G2.5 25000 rpm) (BT MAS 403) (DIN 6499) | 40 | ER11 | 0.5 - 7 | 16 | 16 | M6X1P | 70 | ER11M | E11M |
| BBT40 ER11M 100 ER Collet Chuck (Balanced to G2.5 25000 rpm) (BT MAS 403) (DIN 6499) | 40 | ER11 | 0.5 - 7 | 16 | 16 | M6X1P | 100 | ER11M | E11M |
| BBT40 ER11M 130 ER Collet Chuck (Balanced to G2.5 25000 rpm) (BT MAS 403) (DIN 6499) | 40 | ER11 | 0.5 - 7 | 16 | 16 | M6X1P | 160 | ER11M | E11M |
| BBT40 ER11M 160 ER Collet Chuck (Balanced to G2.5 25000 rpm) (BT MAS 403) (DIN 6499) | 40 | ER11 | 0.5 - 7 | 16 | M6X1 | 160 | ER11M | E11M | |
| BBT40 ER16M 070 ER Collet Chuck (Balanced to G2.5 25000 rpm) (BT MAS 403) (DIN 6499) | 40 | ER16 | 0.5 - 10 | 22 | 22 | M10X1P | 70 | ER16M | E16M |
| BBT40 ER16M 100 ER Collet Chuck (Balanced to G2.5 25000 rpm) (BT MAS 403) (DIN 6499) | 40 | ER16 | 0.5 - 10 | 22 | 22 | M10X1P | 100 | ER16M | E16M |
| BBT40 ER16M 120 ER Collet Chuck (Balanced to G2.5 25000 rpm) (BT MAS 403) (DIN 6499) | 40 | ER16 | 0.5 - 10 | 22 | 22 | M10X1P | 120 | ER16M | E16M |
| BBT40 ER16M 130 ER Collet Chuck (Balanced to G2.5 25000 rpm) (BT MAS 403) (DIN 6499) | 40 | ER16 | 0.5 - 10 | 22 | 22 | M10X1P | 130 | ER16M | E16M |
| BBT40 ER16M 160 ER Collet Chuck (Balanced to G2.5 25000 rpm) (BT MAS 403) (DIN 6499) | 40 | ER16 | 0.5 - 10 | 22 | 22 | M10X1P | 160 | ER16M | E16M |
| BBT40 ER20M 120 ER Collet Chuck (Balanced to G2.5 25000 rpm) (BT MAS 403) (DIN 6499) | 40 | ER20 | 1.0 - 13 | 28 | 28 | M10X1P | 120 | ER20M | E20M |
| BBT40 ER20M 130 ER Collet Chuck (Balanced to G2.5 25000 rpm) (BT MAS 403) (DIN 6499) | 40 | ER20 | 1.0 - 13 | 28 | 28 | M10X1P | 130 | ER20M | E20M |
| BBT40 ER20M 160 ER Collet Chuck (Balanced to G2.5 25000 rpm) (BT MAS 403) (DIN 6499) | 40 | ER20 | 1.0 - 13 | 28 | 28 | M10X1P | 160 | ER20M | E20M |
| BBT40 ER25M 070 ER Collet Chuck (Balanced to G2.5 25000 rpm) (BT MAS 403) (DIN 6499) | 40 | ER25 | 1.0 - 16 | 35 | 35 | M18X1P | 70 | ER25M | E25M |
| BBT40 ER25M 100 ER Collet Chuck (Balanced to G2.5 25000 rpm) (BT MAS 403) (DIN 6499) | 40 | ER25 | 1.0 - 16 | 35 | 35 | M18X1P | 100 | ER25M | E25M |
| BBT40 ER25M 120 ER Collet Chuck (Balanced to G2.5 25000 rpm) (BT MAS 403) (DIN 6499) | 40 | ER25 | 1.0 - 16 | 35 | 35 | M18X1P | 120 | ER25M | E25M |
| BBT40 ER25M 130 ER Collet Chuck (Balanced to G2.5 25000 rpm) (BT MAS 403) (DIN 6499) | 40 | ER25 | 1.0 - 16 | 35 | 35 | M18X1P | 120 | ER25M | E25M |
| BBT40 ER25M 160 ER Collet Chuck (Balanced to G2.5 25000 rpm) (BT MAS 403) (DIN 6499 | 40 | ER25 | 1.0 - 16 | 35 | 35 | M18X1P | 160 | ER25M | E25M |
-30 %
Brand: ToolsEngg
Weight: 1.10kg
Item Name
ISO
Suitable Collet
Collet Capacity
D1
D2
G
L
Nut
Spanner
BBT40 ER11M 070 ER Collet Chuck (Balanced to G2.5 25000 rpm) (BT MAS 403) (DIN 6499)
40
&nbs..
$93.06 USD $132.94 USD
-30 %
Brand: ToolsEngg
Weight: 1.10kg
Item Name
ISO
Suitable Collet
Collet Capacity
D1
D2
G
L
Nut
Spanner
BBT40 ER11M 100 ER Collet Chuck (Balanced to G2.5 25000 rpm) (BT MAS 403) (DIN 6499)
40
&nbs..
$110.75 USD $158.21 USD
-30 %
Brand: ToolsEngg
Weight: 2.00kg
Item Name
ISO
Suitable Collet
Collet Capacity
D1
D2
G
L
Nut
Spanner
BBT40 ER11M 130 ER Collet Chuck (Balanced to G2.5 25000 rpm) (BT MAS 403) (DIN 6499)
40
&nbs..
$127.68 USD $182.40 USD
-30 %
Brand: ToolsEngg
Weight: 1.10kg
Item Name
ISO
Suitable
Collet
Collet
Capacity
D1
G
L
Nut
Spanner
BBT40 ER11M 160 ER Collet Chuck (Balanced to G2.5 25000 rpm) (BT MAS 403) (DIN 6499)
4..
$124.70 USD $178.14 USD
-250x250w.png "BBT40 ER16 070 ER Collet Chuck (Balanced to G2.5 25000 rpm) (BT MAS 403) (DIN 6499)")
-30 %
Brand: ToolsEngg
Weight: 1.29kg
Item Name
ISO
Suitable Collet
Collet Capacity
D1
D2
G
L
Nut
Spanner
BBT40 ER16 070 ER Collet Chuck (Balanced to G2.5 25000 rpm) (BT MAS 403) (DIN 6499)
40
..
$53.04 USD $75.78 USD
-30 %
Brand: ToolsEngg
Weight: 1.46kg
Item Name
ISO
Suitable Collet
Collet Capacity
D1
D2
G
L
Nut
Spanner
BBT40 ER16 100 ER Collet Chuck (Balanced to G2.5 25000 rpm) (BT MAS 403) (DIN 6499)
40
..
$57.70 USD $82.43 USD
-30 %
Brand: ToolsEngg
Weight: 1.50kg
Item Name
ISO
Suitable Collet
Collet Capacity
D1
D2
G
L
Nut
Spanner
BBT40 ER16 130 ER Collet Chuck (Balanced to G2.5 25000 rpm) (BT MAS 403) (DIN 6499)
40
..
$81.76 USD $116.80 USD
-30 %
Brand: ToolsEngg
Weight: 1.76kg
Item Name
ISO
Suitable Collet
Collet Capacity
D1
D2
G
L
Nut
Spanner
BBT40 ER16 160 ER Collet Chuck (Balanced to G2.5 25000 rpm) (BT MAS 403) (DIN 6499)
40
..
$80.03 USD $114.34 USD
-30 %
Brand: ToolsEngg
Weight: 1.10kg
Item Name
ISO
Suitable Collet
Collet Capacity
D1
D2
G
L
Nut
Spanner
BBT40 ER16M 070 ER Collet Chuck (Balanced to G2.5 25000 rpm) (BT MAS 403) (DIN 6499)
40
&nbs..
$70.72 USD $101.02 USD
-30 %
Brand: ToolsEngg
Weight: 1.10kg
Item Name
ISO
Suitable Collet
Collet Capacity
D1
D2
G
L
Nut
Spanner
BBT40 ER16M 100 ER Collet Chuck (Balanced to G2.5 25000 rpm) (BT MAS 403) (DIN 6499)
40
&nbs..
$70.72 USD $101.02 USD
-30 %
Brand: ToolsEngg
Weight: 1.35kg
Item Name
ISO
Suitable Collet
Collet Capacity
D1
D2
G
L
Nut
Spanner
BBT40 ER16M 120 ER Collet Chuck (Balanced to G2.5 25000 rpm) (BT MAS 403) (DIN 6499)
40
&nbs..
$98.66 USD $140.93 USD
-30 %
Brand: ToolsEngg
Weight: 2.00kg
Item Name
ISO
Suitable Collet
Collet Capacity
D1
D2
G
L
Nut
Spanner
BBT40 ER16M 130 ER Collet Chuck (Balanced to G2.5 25000 rpm) (BT MAS 403) (DIN 6499)
40
&nbs..
$115.36 USD $164.80 USD
