| Item Name | SK | Suitable Collet | Collet Capacity | D1 | D2 | G | L | Nut | Spanner |
|---|---|---|---|---|---|---|---|---|---|
| SK50 ER16 70 ER Collet Chuck (AD) (Balanced to G2.5 25000 RPM) (DIN 6499) | 50 | ER16 | 0.5-10 | 32 | - | M10X1P | 70 | UM/ER16 | E16 |
| SK50 ER16 100 ER Collet Chuck (AD) (Balanced to G2.5 25000 RPM) (DIN 6499) | 50 | ER16 | 0.5-10 | 32 | 28 | M10X1P | 100 | UM/ER16 | E16 |
| SK50 ER16 130 ER Collet Chuck (AD) (Balanced to G2.5 25000 RPM) (DIN 6499) | ER16 | 0.5-10 | 32 | 28 | M10X1P | 130 | UM/ER16 | E16 | |
| SK50 ER16 160 ER Collet Chuck (AD) (Balanced to G2.5 25000 RPM) (DIN 6499) | 50 | ER16 | 0.5-10 | 32 | 28 | M10X1P | 160 | UM/ER16 | E16 |
| SK50 ER20 070 ER Collet Chuck (AD) (Balanced to G2.5 25000 RPM) (DIN 6499) | ER20 | 1.0-13 | 35 | - | M10X1P | 70 | UM/ER20 | E20 | |
| SK50 ER20 100 ER Collet Chuck (AD) (Balanced to G2.5 25000 RPM) (DIN 6499) | 50 | ER20 | 1.0-13 | 35 | 33 | M10X1P | 100 | UM/ER20 | E20 |
| SK50 ER20 130 ER Collet Chuck (AD) (Balanced to G2.5 25000 RPM) (DIN 6499) | 50 | ER20 | 1.0-13 | 35 | 33 | M10X1P | 130 | UM/ER20 | E20 |
| SK50 ER20 160 ER Collet Chuck (AD) (Balanced to G2.5 25000 RPM) (DIN 6499) | 50 | ER20 | 1.0-13 | 35 | 33 | M10X1P | 160 | UM/ER20 | E20 |
| SK50 ER25 070 ER Collet Chuck (AD) (Balanced to G2.5 25000 RPM) (DIN 6499) | 50 | ER25 | 1.0-16 | 42 | - | M18X1P | 70 | UM/ER25 | E25 |
| SK50 ER25 100 ER Collet Chuck (AD) (Balanced to G2.5 25000 RPM) (DIN 6499) | 50 | ER25 | 1.0-16 | 42 | 40 | M18X1P | 100 | UM/ER25 | E25 |
| SK40 ER25 130 ER Collet Chuck (AD) (Balanced to G2.5 25000 RPM) (DIN 6499) | 50 | ER25 | 1.0-16 | 42 | 40 | M18X1P | 130 | UM/ER25 | E25 |
| SK50 ER25 160 ER Collet Chuck (AD) (Balanced to G2.5 25000 RPM) (DIN 6499) | 50 | ER25 | 1.0-16 | 42 | 40 | M18X1P | 160 | UM/ER25 | E25 |
| SK50 ER32 070 ER Collet Chuck (AD) (Balanced to G2.5 25000 RPM) (DIN 6499) | 50 | ER32 | 2.0- 20 | 50 | - | M22X1.5P | 70 | UM/ER32 | E32 |
| SK50 ER32 100 ER Collet Chuck (AD) (Balanced to G2.5 25000 RPM) (DIN 6499) | 50 | ER32 | 2.0- 20 | 50 | 48 | M22X1.5P | 100 | UM/ER32 | E32 |
| SK40 ER32 130 ER Collet Chuck (AD) (Balanced to G2.5 25000 RPM) (DIN 6499) | 50 | ER32 | 2.0-20 | 50 | 48 | M22X1.5P | 130 | UM/ER32 | E32 |
| SK50 ER32 160 ER Collet Chuck (AD) (Balanced to G2.5 25000 RPM) (DIN 6499) | 50 | ER32 | 2.0- 20 | 50 | 48 | M22X1.5P | 160 | UM/ER32 | E32 |
| SK50 ER 40 080 ER Collet Chuck (AD) (Balanced to G2.5 25000 RPM) (DIN 6499) | 50 | ER40 | 3.0- 26 | 63 | - | M30X1.5P | 80 | UM/ER40 | E40 |
| SK50 ER 40 100 ER Collet Chuck (AD) (Balanced to G2.5 25000 RPM) (DIN 6499) | 50 | ER40 | 3.0- 26 | 63 | - | M30X1.5P | 100 | UM/ER40 | E40 |
| SK50 ER40 130 ER Collet Chuck (AD) (Balanced to G2.5 25000 RPM) (DIN 6499) | 50 | ER40 | 3.0- 26 | 63 | - | M30X1.5P | 130 | UM/ER40 | E40 |
| SK50 ER 40 160 ER Collet Chuck (AD) (Balanced to G2.5 25000 RPM) (DIN 6499) | 50 | ER40 | 3.0- 26 | 63 | 60 | M30X1.5P | 160 | UM/ER40 | E40 |
| SK50 ER50 100 ER Collet Chuck (AD) (Balanced to G2.5 15000 RPM) (DIN 6499) | 50 | ER50 | 10.0- 34 | 78 | - | M16X2P | 100 | UM/ER50 | E50 |
| SK50 ER50 160 ER Collet Chuck (AD) (Balanced to G2.5 15000 RPM) (DIN 6499) | 50 | ER50 | 10.0-34 | 78 | - | M16X2P | 160 | UM/ER50 | E50 |
| SK50 ER16 70 ER Collet Chuck (AD+B) (Balanced to G2.5 25000 RPM) (DIN 6499) | 50 | ER16 | 0.5 - 10 | 32 | - | M10X1P | 70 | UM/ER16 | E16 |
| SK50 ER16 100 ER Collet Chuck (AD+B) (Balanced to G2.5 25000 RPM) (DIN 6499) | 50 | ER16 | 0.5 - 10 | 32 | 28 | M10X1P | 100 | UM/ER16 | E16 |
| SK50 ER16 130 ER Collet Chuck (AD+B) (Balanced to G2.5 25000 RPM) (DIN 6499) | 50 | ER16 | 0.5-10 | 32 | 28 | M10X1P | 130 | UM/ER16 | ER16 |
| SK50 ER16 160 ER Collet Chuck (AD+B) (Balanced to G2.5 25000 RPM) (DIN 6499) | 50 | ER16 | 0.5 - 10 | 32 | 28 | M10X1P | 160 | UM/ER16 | E16 |
| SK50 ER20 70 ER Collet Chuck (AD+B) (Balanced to G2.5 25000 RPM) (DIN 6499) | 50 | ER20 | 1.0-13 | 35 | - | M10X1P | 70 | UM/ER20 | ER20 |
| SK50 ER20 100 ER Collet Chuck (AD+B) (Balanced to G2.5 25000 RPM) (DIN 6499) | 50 | ER20 | 1.0-13 | 35 | 33 | M10X1P | 100 | UM/ER20 | ER20 |
| SK50 ER20 130 ER Collet Chuck (AD+B) (Balanced to G2.5 25000 RPM) (DIN 6499) | 50 | ER20 | 1.0-13 | 35 | 33 | M10X1P | 130 | UM/ER20 | ER20 |
| SK50 ER20 160 ER Collet Chuck (AD+B) (Balanced to G2.5 25000 RPM) (DIN 6499) | 50 | ER20 | 1.0-13 | 35 | 33 | M10X1P | 160 | UM/ER20 | ER20 |
| SK50 ER25 070 ER Collet Chuck (AD+B) (Balanced to G2.5 25000 RPM) (DIN 6499) | 50 | ER25 | 1.0-16 | 42 | - | M18X1P | 70 | UM/ER25 | E25 |
| SK50 ER25 100 ER Collet Chuck (AD+B) (Balanced to G2.5 25000 RPM) (DIN 6499) | 50 | ER25 | 1.0-16 | 42 | 40 | M18X1P | 100 | UM/ER25 | E25 |
| SK50 ER25 130 ER Collet Chuck (AD+B) (Balanced to G2.5 25000 RPM) (DIN 6499) | 50 | ER25 | 1.0-16 | 42 | 40 | M18X1P | 130 | UM/ER25 | E25 |
| SK50 ER25 160 ER Collet Chuck (AD+B) (Balanced to G2.5 25000 RPM) (DIN 6499) | 50 | ER25 | 1.0-16 | 42 | 40 | M18X1P | 160 | UM/ER25 | E25 |
| SK50 ER32 070 ER Collet Chuck (AD+B) (Balanced to G2.5 25000 RPM) (DIN 6499) | 50 | ER32 | 2.0-20 | 50 | - | M22X1.5P | 70 | UM/ER32 | E32 |
| SK50 ER32 100 ER Collet Chuck (AD+B) (Balanced to G2.5 25000 RPM) (DIN 6499) | 50 | ER32 | 2.0-20 | 50 | 48 | M22X1.5P | 100 | UM/ER32 | E32 |
| SK50 ER32 130 ER Collet Chuck (AD+B) (Balanced to G2.5 25000 RPM) (DIN 6499) | 50 | ER32 | 2.0-20 | 50 | 48 | M22X1.5P | 130 | UM/ER32 | E32 |
| SK50 ER32 160 ER Collet Chuck (AD+B) (Balanced to G2.5 25000 RPM) (DIN 6499) | 50 | ER32 | 2.0-20 | 50 | 48 | M22X1.5P | 160 | UM/ER32 | E32 |
| SK50 ER 40 080 ER Collet Chuck (AD+B) (Balanced to G2.5 25000 RPM) (DIN 6499) | 50 | ER40 | 3.0-26 | 63 | - | M30X1.5P | 80 | UM/ER40 | E40 |
| SK50 ER 40 100 ER Collet Chuck (AD+B) (Balanced to G2.5 25000 RPM) (DIN 6499) | 50 | ER40 | 3.0-26 | 63 | - | M30X1.5P | 100 | UM/ER40 | E40 |
| SK50 ER 40 130 ER Collet Chuck (AD+B) (Balanced to G2.5 25000 RPM) (DIN 6499) | 50 | ER40 | 3.0-26 | 63 | - | M30X1.5P | 130 | UM/ER40 | E40 |
| SK50 ER 40 160 ER Collet Chuck (AD+B) (Balanced to G2.5 25000 RPM) (DIN 6499) | 50 | ER40 | 3.0-26 | 63 | 60 | M30X1.5P | 160 | UM/ER40 | E40 |
| SK50 ER50 100 ER Collet Chuck (AD+B) (Balanced to G2.5 25000 RPM) (DIN 6499) | 50 | ER50 | 10.0-34 | 78 | - | M16X2P | 100 | UM/ER50 | E50 |
| SK50 ER50 160 ER Collet Chuck (AD+B) (Balanced to G2.5 25000 RPM) (DIN 6499) | 50 | ER50 | 10.0- 34 | 78 | - | M16X2P | 160 | UM/ER50 | E50 |
| SK50 ER16M 100 ER Collet Chuck (AD+B) (Balanced to G2.5 25000 RPM) (DIN 6499) | 50 | ER16 | 0.5-10 | 22 | 22 | M10X1P | 100 | UM/ER16M | E16M |
| SK50 ER16M 130 ER Collet Chuck (AD+B) (Balanced to G2.5 25000 RPM) (DIN 6499) | 50 | ER16 | 0.5-10 | 22 | 22 | M10X1P | 130 | UM/ER16M | E16M |
| SK50 ER16M 160 ER Collet Chuck (AD+B) (Balanced to G2.5 25000 RPM) (DIN 6499) | 50 | ER16 | 0.5-10 | 22 | 22 | M10X1P | 160 | UM/ER16M | E16M |
-30 %
Brand: Spindle Tooling Division
Weight: 4.00kg
Item Name
SK
Suitable
Collet
Collet capacity
D1
L
Suitable Nut
SK40 ER32 130 ER Collet Chuck (AD) (Balanced to G2.5 25000 RPM) (DIN 6499)
50
..
$123.26 USD $176.08 USD
-250x250w.png "SK50 ER 40 080 ER Collet Chuck (AD) (Balanced to G2.5 25000 RPM) (DIN 6499)")
-30 %
Brand: Spindle Tooling Division
Weight: 3.72kg
Item Name
SK
Suitable
Collet
Collet
Capacity
D1
D2
G
L
Nut
Spanner
SK50 ER 40 080 ER Collet Chuck (AD) (Balanced to G2.5 25000 RPM) (DIN 649..
$60.14 USD $85.92 USD
-30 %
Brand: Spindle Tooling Division
Weight: 3.71kg
Item Name
SK
Suitable
Collet
Collet
Capacity
D1
D2
G
L
Nut
Spanner
SK50 ER 40 080 ER Collet Chuck (AD+B) (Balanced to G2.5 25000 RPM) (D..
$67.42 USD $96.33 USD
-30 %
Brand: Spindle Tooling Division
Weight: 4.22kg
Item Name
SK
Suitable
Collet
Collet
Capacity
D1
D2
G
L
Nut
Spanner
SK50 ER 40 100 ER Collet Chuck (AD) (Balanced to G2.5 25000 RPM) (DIN 6499..
$86.56 USD $123.66 USD
-30 %
Brand: Spindle Tooling Division
Weight: 4.22kg
Item Name
SK
Suitable
Collet
Collet
Capacity
D1
D2
G
L
Nut
Spanner
SK50 ER 40 100 ER Collet Chuck (AD+B) (Balanced to G2.5 25000 RPM) (D..
$95.69 USD $136.69 USD
-30 %
Brand: Spindle Tooling Division
Weight: 4.30kg
Item Name
SK
Suitable
Collet
Collet
Capacity
D1
D2
G
L
Nut
Spanner
SK50 ER40 130 ER Collet Chuck (AD) (Balanced to G2.5 25000 RPM)..
$104.03 USD $148.61 USD
-30 %
Brand: Spindle Tooling Division
Weight: 5.58kg
Item Name
SK
Suitable
Collet
Collet
Capacity
D1
D2
G
L
Nut
Spanner
SK50 ER 40 160 ER Collet Chuck (AD) (Balanced to G2.5 25000 RPM) (DIN 6499..
$104.05 USD $148.64 USD
-30 %
Brand: Spindle Tooling Division
Weight: 5.58kg
Item Name
SK
Suitable
Collet
Collet
Capacity
D1
D2
G
L
Nut
Spanner
SK50 ER 40 160 ER Collet Chuck (AD+B) (Balanced to G2.5 25000 RPM) (D..
$115.51 USD $165.01 USD
-30 %
Brand: Spindle Tooling Division
Weight: 3.28kg
Item Name
SK
Suitable Collet
Collet Capacity
D1
D2
G
L
Nut
Spanner
SK50 ER16 70 ER Collet Chuck (AD) (Balanced to G2.5 25000 RPM) (DIN 6499)..
$59.23 USD $84.62 USD
-30 %
Brand: Spindle Tooling Division
Weight: 3.28kg
Item Name
SK
Suitable
Collet
Collet
Capacity
D1
D2
G
L
Nut
Spanner
SK50 ER16 70 ER Collet Chuck (AD+B) (Balanced to G2.5 25000 RPM) ..
$64.71 USD $92.43 USD
-30 %
Brand: Spindle Tooling Division
Weight: 3.44kg
Item Name
SK
Suitable Collet
Collet Capacity
D1
D2
G
L
Nut
Spanner
SK50 ER16 100 ER Collet Chuck (AD) (Balanced to G2.5 25000 RPM) (DIN 6499..
$71.08 USD $101.53 USD
-30 %
Brand: Spindle Tooling Division
Weight: 3.44kg
Item Name
SK
Suitable
Collet
Collet
Capacity
D1
D2
G
L
Nut
Spanner
SK50 ER16 100 ER Collet Chuck (AD+B) (Balanced to G2.5 25000 RPM)..
$78.36 USD $111.94 USD
