| Item Name | SK | Suitable Collet | Collet Capacity | D1 | D2 | G | L | Nut | Spanner |
|---|---|---|---|---|---|---|---|---|---|
| SK40 ER16 200 ER Collet Chuck (AD) (Balanced to G2.5 25000 RPM) (DIN 6499) | 40 | ER16 | 0.5-10 | 32 | 30 | 200 | M10x1.5P | UM/ER16 | E16 |
| SK40 ER16 250 ER Collet Chuck (AD) (Balanced to G2.5 25000 RPM) (DIN 6499) | 40 | ER16 | 0.5-10 | 32 | 30 | 250 | M10x1.5P | UM/ER16 | E16 |
| SK40 ER16 300 ER Collet Chuck (AD) (Balanced to G2.5 25000 RPM) (DIN 6499) | 40 | ER16 | 0.5-10 | 32 | 30 | 300 | M10x1.5P | UM/ER16 | E16 |
| SK40 ER20 200 ER Collet Chuck (AD) (Balanced to G2.5 25000 RPM) (DIN 6499) | 40 | ER20 | 1.0-13 | 35 | 34 | 200 | M10x1.5P | UM/ER20 | E20 |
| SK40 ER20 250 ER Collet Chuck (AD) (Balanced to G2.5 25000 RPM) (DIN 6499) | 40 | ER20 | 1.0-13 | 35 | 34 | 250 | M10x1.5P | UM/ER20 | E20 |
| SK40 ER20 300 ER Collet Chuck (AD) (Balanced to G2.5 25000 RPM) (DIN 6499) | 40 | ER20 | 1.0-13 | 35 | 34 | 300 | M10x1.5P | UM/ER20 | E20 |
| SK40 ER25 200 ER Collet Chuck (AD) (Balanced to G2.5 25000 RPM) (DIN 6499) | 40 | ER25 | 1.0-16 | 42 | 40 | 200 | M16x2P | UM/ER25 | E25 |
| SK40 ER25 250 ER Collet Chuck (AD) (Balanced to G2.5 25000 RPM) (DIN 6499) | 40 | ER25 | 1.0-16 | 42 | 40 | 250 | M16x2P | UM/ER25 | E25 |
| SK40 ER25 300 ER Collet Chuck (AD+B) (Balanced to G2.5 25000 RPM) (DIN 6499) | 40 | ER25 | 1.0-16 | 42 | 40 | 300 | M16x2P | UM/ER25 | E25 |
| SK40 ER32 200 ER Collet Chuck (AD) (Balanced to G2.5 25000 RPM) (DIN 6499) | 40 | ER32 | 2.0-20 | 50 | 48 | 200 | M10x1.5P | UM/ER32 | E32 |
| SK40 ER32 250 ER Collet Chuck (AD) (Balanced to G2.5 25000 RPM) (DIN 6499) | 40 | ER32 | 2.0-20 | 50 | 48 | 250 | M10x1.5P | UM/ER32 | E32 |
| SK40 ER32 300 ER Collet Chuck (AD) (Balanced to G2.5 25000 RPM) (DIN 6499) | 40 | ER32 | 2.0-20 | 50 | 48 | 300 | M10x1.5P | UM/ER32 | E32 |
| SK40 ER40 200 ER Collet Chuck (AD) (Balanced to G2.5 25000 RPM) (DIN 6499) | 40 | ER40 | 3.0-26 | 63 | 52 | 200 | M16x2P | UM/ER40 | E40 |
| SK40 ER40 250 ER Collet Chuck (AD) (Balanced to G6.3 15000 RPM) (DIN 6499) | 40 | ER40 | 3.0-26 | 63 | 52 | 250 | M16 x 2P | UM/ER40 | E40 |
| SK40 ER40 300 ER Collet Chuck (AD) (Balanced to G2.5 25000 RPM) (DIN 6499) | 40 | ER40 | 3.0-26 | 63 | 52 | 300 | M16x2P | UM/ER40 | E40 |
